Fusion technology / energy
A MONTE-CARLO CODE FOR CALCULATING COLLISION PHENOMENA IN RANDOMIZED TARGETS
Ref.-No.: 1801-6323-WT
IT / Software / Bioinformatics
Fusion technology / energy

The invention relates to a Monte-Carlo program implemented in Fortran 90. It treats the bombardment of incident ions on different target structures such as mono-atomic targets, layer structures or composition target structures. The two general cases considered in the code are the static case, where the target composition is fixed during the simulation, and the dynamic case, where modifications of the target caused by the ion bombardment are taken into account.
A further development of the ...
Read more … A MONTE-CARLO CODE FOR CALCULATING COLLISION PHENOMENA IN RANDOMIZED TARGETS
Adaptive deflection technology to reduce thermal hotspots caused by charged particles
Ref.-No.: 1402-6785-WT-FG
Fusion technology / energy

In fusion reactors and similar high-energy technologies, charged particles can strike certain surfaces and cause significant localized heating. This can lead to material fatigue and component damage. The invention presented here uses an innovative method to reduce the thermal stress by deflecting the particles. By controlling magnetic and electric fields, the point of impact of the particles is continuously shifted so that the thermal load is distributed over a larger area. Temperature-controlled ...
Read more … Adaptive deflection technology to reduce thermal hotspots caused by charged particles
Advanced collector sweeping with homogenous power deposition of the electron beam in high-power rf vacuum-tubes
Ref.-No.: 1801-3749-WT
Sensors, Devices and Components
Fusion technology / energy
This invention includes two alternative advanced methods to achieve a homogenous collector power distribution, which improves the collector capability of high power vacuum-tubes by a factor of two as compared to conventional methods. Furthermore the applied method has a high flexibility to vary the power distribution over a wide range of profiles and match the deposition profiles to different designs of collectors in existing or future electron tubes.
Bildleiter
Ref.-No.: 1801-6386-WT
Sensors, Devices and Components
Fusion technology / energy

Die Erfindung betrifft einen Bildleiter, der insbesondere für den Einsatz in einer Umgebung mit radioaktiver Strahlung geeignet ist. In einer solchen Umgebung verringert sich die Transmission des Bildleiters mit der Zeit. Bekannterweise kann die Transmission des Bildleiters durch Erwärmen auf eine Temperatur im Bereich von 100° bis 300° regeneriert werden. Weil dieses Erwärmen bisher in einem Ofen erfolgte, implizierte das Regenerieren des Bildleiters seinen Abbau von seinem Betriebsort, ...
Compact Stellarator-Tokamak Hybrid: Enhanced Plasma Stability and Efficient Fusion Reactor Design
Ref.-No.: 1402-6712-WT
Fusion technology / energy

This invention introduces a novel hybrid fusion reactor concept that combines the advantages of tokamaks and stellarators. In tokamaks the magnetic confinement field is generated by toroidal coils and the plasma current driven by a central solenoid coil, while in stellarators the magnetic confinement field is created by a complex magnetic coil system. The proposed design integrates a single type of simple quasi-axisymmetric (QA) coil to introduce 3D shaping effects while maintaining a compact ...
Device for deflecting a light and/or microwave beam with automatic beam tracking
Ref.-No.: 1402-6628-WT
Fusion technology / energy
This innovative device enables precise deflection of light/microwave beams with automatic beam tracking. Thanks to a specially developed hinge system with an integrated reflector, the beam can be guided reliably and with low loss to the desired target point despite the movement of the beam guide. This is particularly advantageous for applications in high-precision optics, sensor technology and plasma physics. The system is characterized by high stability and durability due to the use of low-wear ...
Read more … Device for deflecting a light and/or microwave beam with automatic beam tracking
High-Precision Rotation Holder for Optical Components
Ref.-No.: 1402-4973-WT
Sensors, Devices and Components
Fusion technology / energy

The invention presents a high-precision rotation holder designed for optical components such as polarization filters. This innovative device features a rotor with an axial hollow shaft and an air-bearing system for frictionless rotation. Driven by an airflow turbine, the holder incorporates an angle encoder for precise measurement of the rotational position. Key applications include polarimetry in the terahertz spectrum, enabling advanced analysis of electromagnetic radiation. The invention ensures ...
Read more … High-Precision Rotation Holder for Optical Components
Ion beam extraction apparatus and method for creating an ion beam
Ref.-No.: 1801-5973-WT
Fusion technology / energy
This innovative ion beam extraction system enhances flexibility in beam parameter adjustment and improves the efficiency of ion beam generation. The system combines an ion source with an adjustable grid assembly, where grid spacing can be precisely controlled via a motorized mechanism. This setup allows for optimal perveance tuning and minimizes beam divergence, significantly improving performance under varying operating conditions. While primarily designed for Neutral Beam Injection (NBI) in ...
Read more … Ion beam extraction apparatus and method for creating an ion beam
Method and measuring device for examining the hydrogen permeability of a test object
Ref.-No.: 1801-5807-WT
Fusion technology / energy
This invention presents a method and apparatus for investigating the hydrogen permeability of materials, offering a simplified and cost-effective solution to test the tightness of a material. A sensor is placed on one side of the test object, while a hydrogen-containing test gas is applied to the opposite side. The hydrogen permeating through the material interacts with a sensitive sensor layer, causing measurable physical changes such as color shifts. These changes provide real-time, spatially ...
Read more … Method and measuring device for examining the hydrogen permeability of a test object
Optical Fiber Feedthrough for a Vacuum Chamber
Ref.-No.: 1801-6480-WT
Fusion technology / energy
This invention relates to an optical fiber vacuum feedthrough designed to transmit optical signals between the inside and outside of the vacuum chamber. Traditional methods often require frequent replacement of flanges or optical fibers due to leakage over time, and the high pressure applied to the optical fibers led to transmission losses. In order to address these issues, the presented optical fiber feedthrough comprises a compression device which compresses sealing elements axially along the ...
Safety apparatus and method for monitoring a light path of a laser beam, and applications of same
Ref.-No.: 1801-6105-WT
Sensors, Devices and Components
Fusion technology / energy

The invention enables a fast and effective safety for persons (or obstacles) being in danger of hitting the beam of powerful lasers like YAG lasers. While being extremely powerful, the YAG laser light is invisible to the human eye. The safety mechanism is based on a harmless, visible laser light, i.e., cylindrically surrounding the YAG beam a shutter mechanism (i.e., with an entrance of cylindrical symmetry and made of synthetic material). The safety laser light is controlled by a ring (or sector) ...
SIMNRA 7 software
Ref.-No.: 1801-4849-WT
IT / Software / Bioinformatics
Fusion technology / energy
SIMNRA is a Microsoft Windows program for the simulation of energy spectra for ion beam analysis with incident ions from about 100 keV to many MeV. SIMNRA can be used for the simulation of Rutherford backscattering (RBS), elastic backscattering with non-Rutherford cross-sections (EBS), nuclear reaction analysis (NRA), elastic recoil detection analysis (ERDA), and medium energy ion scattering (MEIS). Almost 3000 different non-Rutherford and nuclear reactions cross-sections for incident protons, ...
